一、实现效果

前端使用LogicFlow框架绘制流程图,可以导出为xml工作流标准格式数据,通过xml文件传递到后端进行Flowable流程注册,并保存到数据库中。
在这里插入图片描述

二、BPM传输文件格式(.xml)

如需添加承办人的话,需要在LogicFlow导出文件的基础上手动添加xmlns:flowable="http://flowable.org/bpmn"flowable插件,不然后台无法识别flowable:candidateUsers

<bpmn:definitions xmlns:flowable="http://flowable.org/bpmn" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:bpmn="http://www.omg.org/spec/BPMN/20100524/MODEL" xmlns:bpmndi="http://www.omg.org/spec/BPMN/20100524/DI" xmlns:dc="http://www.omg.org/spec/DD/20100524/DC" xmlns:di="http://www.omg.org/spec/DD/20100524/DI" id="Definitions_5588fe5_6" targetNamespace="http://logic-flow.org" exporter="logicflow" exporterVersion="1.2.0">
  <bpmn:process isExecutable="true" id="Process_2a9c067_6">
    <bpmn:startEvent id="Event_14efe0e" name="开始节点" flowable:candidateUsers="admin,admin1,admin2">
      <bpmn:outgoing>Flow_a3e7d0c</bpmn:outgoing>
    </bpmn:startEvent>
    <bpmn:userTask id="Activity_602107f" name="普通节点" flowable:candidateUsers="uesr,uesr1,uesr2">
      <bpmn:incoming>Flow_a3e7d0c</bpmn:incoming>
      <bpmn:outgoing>Flow_3f9a386</bpmn:outgoing>
    </bpmn:userTask>
    <bpmn:endEvent id="Event_49a11b4" name="结束节点">
      <bpmn:incoming>Flow_3f9a386</bpmn:incoming>
    </bpmn:endEvent>
      <bpmn:sequenceFlow id="Flow_a3e7d0c" sourceRef="Event_14efe0e" targetRef="Activity_602107f"/>
      <bpmn:sequenceFlow id="Flow_3f9a386" sourceRef="Activity_602107f" targetRef="Event_49a11b4"/>
  </bpmn:process>
  <bpmndi:BPMNDiagram id="BPMNDiagram_1">
    <bpmndi:BPMNPlane id="BPMNPlane_1" bpmnElement="Process_2a9c067">
        <bpmndi:BPMNEdge id="Flow_a3e7d0c_di" bpmnElement="Flow_a3e7d0c">
            <di:waypoint x="343" y="164"/>
            <di:waypoint x="448" y="164"/>
        </bpmndi:BPMNEdge>
        <bpmndi:BPMNEdge id="Flow_3f9a386_di" bpmnElement="Flow_3f9a386">
            <di:waypoint x="548" y="164"/>
            <di:waypoint x="665" y="164"/>
        </bpmndi:BPMNEdge>
        <bpmndi:BPMNShape id="Event_14efe0e_di" bpmnElement="Event_14efe0e">
          <dc:Bounds x="305" y="144" width="40" height="40"/>
          <bpmndi:BPMNLabel>
            <dc:Bounds x="305" y="197" width="40" height="14"/>
          </bpmndi:BPMNLabel>
        </bpmndi:BPMNShape>
        <bpmndi:BPMNShape id="Activity_602107f_di" bpmnElement="Activity_602107f">
          <dc:Bounds x="448" y="124" width="100" height="80"/>
          <bpmndi:BPMNLabel>
            <dc:Bounds x="478" y="157" width="40" height="14"/>
          </bpmndi:BPMNLabel>
        </bpmndi:BPMNShape>
        <bpmndi:BPMNShape id="Event_49a11b4_di" bpmnElement="Event_49a11b4">
          <dc:Bounds x="663" y="144" width="40" height="40"/>
          <bpmndi:BPMNLabel>
            <dc:Bounds x="663" y="197" width="40" height="14"/>
          </bpmndi:BPMNLabel>
        </bpmndi:BPMNShape>
    </bpmndi:BPMNPlane>
  </bpmndi:BPMNDiagram>
</bpmn:definitions>

三、前端框架(LogicFlow)

  1. LogicFlow.vue
<template>
    <div class="container" ref="container"></div>
    <BpmnNodePanel :lf="lf"></BpmnNodePanel>
    <div class="node-item">
      <div class="node-item-icon bpmn-save" @click="saveNode()"></div>
      <span class="node-label">保存</span>
      <div class="node-item-icon bpmn-save" @click="cleanNode()"></div>
      <span class="node-label">清空</span>
      <div class="node-item-icon bpmn-save" @click="reloadNode()"></div>
      <span class="node-label">加载</span>
      <div class="node-item-icon bpmn-save" @click="deleteNode()"></div>
      <span class="node-label">删除</span>
      <div class="node-item-icon bpmn-save" @click="getList()"></div>
      <span class="node-label">获取定义流程</span>
      <div class="node-item-icon bpmn-save" @click="flowRun()"></div>
      <span class="node-label">工作流实例</span>
    </div>
</template>
<script>
import LogicFlow from '@logicflow/core'
import '@logicflow/core/dist/style/index.css'
import { BpmnElement, BpmnXmlAdapter, Menu } from '@logicflow/extension'
import '@logicflow/extension/lib/style/index.css'
import BpmnNodePanel from "./BpmnNodePanel.vue"
import { addFlow, infoFlow, deleteFlow, getDeployList, flowRun } from "../api/server"
import { addFlowable, addProp, getTypeNameByTag, setValueByTag } from '../utils/xml'

export default {
    data() {
        return {
            lf: void 0,
            xmlData: void 0,
            definitionsId: void 0,
            processId: void 0,
        }
    },
    components: { BpmnNodePanel },
    created() {},
    mounted() {
        this.loadFlow()
    },
    methods: {
        loadFlow() {
            LogicFlow.use(BpmnElement)
            LogicFlow.use(BpmnXmlAdapter)
            LogicFlow.use(Menu)

            //初始化
            this.lf = new LogicFlow({
                container: this.$refs.container,
                stopScrollGraph: true,
                stopZoomGraph: true,
                grid: false,
                keyboard: {
                    enabled: true,
                },
            });
            // this.lf.setDefaultEdgeType('bezier')
            this.lf.render();
        },
        // 保存
        saveNode() {
            // 获取xml数据
            this.xmlData = this.lf.getGraphData();

            // 添加flowable扩展
            this.xmlData = addFlowable(this.xmlData)

            // 判断是否为文档编辑
            if (this.processId) {
                // 修改为原流程id
                this.xmlData = setValueByTag(this.xmlData, 'bpmn:definitions', 'id', this.definitionsId)
                this.xmlData = setValueByTag(this.xmlData, 'bpmn:process', 'id', this.processId)
            } else {
                // 添加节点用户 个人assignee  候选人candidateUsers 候选组候选人candidateGroups 动态设置${employee}
                // this.xmlData = addProp(this.xmlData, 'bpmn:startEvent', 'flowable:candidateUsers', 'zhao,qian,sun')
                this.xmlData = addProp(this.xmlData, 'bpmn:userTask', 'flowable:candidateUsers', 'li,zhou,wang')
            }

            const data = {
                name: '测试流程',
                xml: this.xmlData
            }

            // 请求后台接口(添加工作流)
            addFlow(data)
                .then(res => {
                    console.log(res)
                })
                .catch(err => {
                    console.log(err)
                })
        },
        // 清除
        cleanNode() {
            this.lf.clearData()
        },
        // 重新加载
        reloadNode() {
            // 查询数据
            const data = {
                id: 'ff292b5d-4193-11ee-8e48-502b73dc5fce',
                name: '测试流程'
            }
            infoFlow(data)
                .then(res => {
                    if (res.result) {
                        // 获取processId
                        const definitionsNodes = getTypeNameByTag(res.result, 'bpmn:definitions')
                        const processNodes = getTypeNameByTag(res.result, 'bpmn:process')
                        this.definitionsId = definitionsNodes.id
                        this.processId = processNodes.id
                        // 渲染数据
                        this.lf.render(res.result);
                    }
                    console.log(res)
                })
                .catch(err => {
                    console.log(err)
                })
        },
        // 删除数据
        deleteNode() {
            // 查询数据
            const data = {
                id: ''
            }
            deleteFlow(data)
                .then(res => {
                    console.log(res)
                })
                .catch(err => {
                    console.log(err)
                })
        },
        // 获取数据
        getList() {
            getDeployList()
                .then(res => {
                    console.log(res)
                })
                .catch(err => {
                    console.log(err)
                })
        },
        // 流程实例
        flowRun() {
            flowRun()
                .then(res => {
                    console.log(res)
                })
                .catch(err => {
                    console.log(err)
                })
        },
    },
}
</script>
<style scoped>
.container{
    width: 100%;
    height: 100%;
}

.node-item {
  position: absolute;
  top: 350px;
  left: 10px;
  width: 50px;
  padding: 10px;
  background-color: white;
  box-shadow: 0 0 10px 1px rgb(228, 224, 219);
  border-radius: 6px;
  text-align: center;
  z-index: 101;
}
.node-item-icon {
  width: 30px;
  height: 30px;
  margin-left: 10px;
  background-size: cover;
}
.node-label {
  font-size: 12px;
  margin-top: 5px;
  user-select: none;
}

.bpmn-save {
    center center no-repeat;
  cursor: grab;
}
</style>

2.BpmnNodePanel.vue

<template>
  <div class="node-panel">
    <!-- <div class="node-item" @mousedown="openSelection()">
      <div class="node-item-icon bpmn-selection"></div>
      <span class="node-label">选区</span>
    </div> -->
    <div class="node-item" @mousedown="addStartNode()">
      <div class="node-item-icon bpmn-start"></div>
      <span class="node-label">开始节点</span>
    </div>
    <div class="node-item" @mousedown="addUserTask()">
      <div class="node-item-icon bpmn-user"></div>
      <span class="node-label">普通节点</span>
    </div>
    <!-- <div class="node-item" @mousedown="addServiceTask()">
      <div class="node-item-icon bpmn-service"></div>
      <span class="node-label">系统</span>
    </div> -->
    <!-- <div class="node-item" @mousedown="addGateWay()">
      <div class="node-item-icon bpmn-gateway"></div>
      <span class="node-label">判断</span>
    </div> -->
    <div class="node-item" @mousedown="addEndNode()">
      <div class="node-item-icon bpmn-end"></div>
      <span class="node-label">结束节点</span>
    </div>
  </div>
</template>
<script>
import LogicFlow from '@logicflow/core';
export default {
  name: "BpmnNodePanel",
  data() {
    return {}
  },
  props: {
    lf: Object,
  },

  mounted() {
    //选区框选使用的
    let lf = this.$props.lf
    lf &&
      lf.on("selection:selected", () => {
          lf.updateEditConfig({
          stopMoveGraph: false,
        });
      });
  },
  methods: {
    openSelection() {
      (this.$props.lf).updateEditConfig({
        stopMoveGraph: true
      });
    },
    addStartNode() {
      (this.$props.lf).dnd.startDrag({
        type: "bpmn:startEvent",
        text: "开始节点",
      });
    },
    addUserTask() {
      (this.$props.lf).dnd.startDrag({
        type: "bpmn:userTask",
        text: "普通节点",
      });
    },
    addServiceTask() {
      (this.$props.lf).dnd.startDrag({
        type: "bpmn:serviceTask",
        text: "系统",
      });
    },
    addGateWay() {
      (this.$props.lf).dnd.startDrag({
        type: "bpmn:exclusiveGateway",
        text: "判断",
      });
    },
    addEndNode() {
      (this.$props.lf).dnd.startDrag({
        type: "bpmn:endEvent",
        text: "结束节点",
      });
    },
  },
};
</script>
<style>
.node-panel {
  position: absolute;
  top: 100px;
  left: 10px;
  width: 50px;
  padding: 10px;
  background-color: white;
  box-shadow: 0 0 10px 1px rgb(228, 224, 219);
  border-radius: 6px;
  text-align: center;
  z-index: 101;
}
.node-item {
  margin-bottom: 10px;
}
.node-item-icon {
  width: 30px;
  height: 30px;
  margin-left: 10px;
  background-size: cover;
}
.node-label {
  font-size: 12px;
  margin-top: 5px;
  user-select: none;
}

.bpmn-selection {
    center center no-repeat;
  cursor: grab;
}

.bpmn-start {
    center center no-repeat;
  cursor: grab;
}
.bpmn-end {
    center center no-repeat;
  cursor: grab;
}
.bpmn-user {
    center center no-repeat;
  cursor: grab;
}
.bpmn-gateway {
    center center no-repeat;
  cursor: grab;
}

.bpmn-service {
    center center no-repeat;
  cursor: grab;
}
</style>

3.xml.js

/**
 * 添加flowable扩展
 * @param {*} xmlstr
 * @returns
 */
export function addFlowable(xmlstr) {
    const part1 = xmlstr.slice(0, 43); // 从开头到指定位置之前的部分
    const part2 = xmlstr.slice(43); // 从指定位置到末尾的部分
    const newString = part1 + 'xmlns:flowable="http://flowable.org/bpmn" ' + part2; // 拼接成新的字符串

    return newString
}

/**
 * 添加属性信息
 * @param {*} xmlstr
 * @returns
 */
export function addProp(xmlstr, Elements, key, value) {
    // 创建一个XML文档对象
    const parser = new DOMParser();
    const xmlDoc = parser.parseFromString(xmlstr, 'application/xml');

    // 查找元素
    const userTaskElement = xmlDoc.getElementsByTagName(Elements);
    for (let i = 0; i < userTaskElement.length; i++) {
        if (!userTaskElement[i].attributes[key]) {
            userTaskElement[i].setAttribute(key, value);
        }
    }

    // 将修改后的XML文档转换回字符串
    const xmlSerializer = new XMLSerializer();
    const modifiedXmlString = xmlSerializer.serializeToString(xmlDoc);

    return modifiedXmlString;
}

/**
 *根据标签名称返回xml内容,标签名必须唯一,若不满足,修改方法
 * @param {*} xmlstr xml字符串
 * @param {element} tagName 标签名称,如<Name>
 */
export function getTypeNameByTag(xmlstr, tagName) {
    const parser = new DOMParser()
    const xmlDoc = parser.parseFromString(xmlstr, 'application/xml')
    const nameNodes = xmlDoc.getElementsByTagName(tagName)[0]
    if (nameNodes) {
        return nameNodes
    } else {
        return false
    }
}

/**
 * 根据标签名称修改内容
 * @param {*} xmlstr xml字符串
 * @param {element} tagName 标签名称,如<Name>
 * @param {*} key 修改对应key
 * @param {*} value 修改值value
 * @returns
 */
export function setValueByTag(xmlstr, tagName, key, value) {
    // 字符串转xml
    const parser = new DOMParser()
    const xmlDoc = parser.parseFromString(xmlstr, 'application/xml')
    const nameNodes = xmlDoc.getElementsByTagName(tagName)[0]
    nameNodes.setAttribute(key, value);
    // xml转字符串
    const s = new XMLSerializer();
    const xml = s.serializeToString(xmlDoc);

    return xml;
}

4.server.js

import request from '../utils/request';
const url = 'http://localhost:8088'

/**
 * 添加(编辑)工作流
 * @param {*} data
 * @returns
 */
export function addFlow(data) {
    return request({
        url: url + '/flow/addFlow',
        method: 'post',
        data,
    });
}

/**
 * 查询工作流
 * @param {*} data
 * @returns
 */
export function infoFlow(data) {
    return request({
        url: url + '/flow/infoFlow',
        method: 'post',
        data,
    });
}

/**
 * 删除工作流
 * @param {*} data
 * @returns
 */
export function deleteFlow(data) {
    return request({
        url: url + '/flow/deleteFlow',
        method: 'post',
        data,
    });
}

/**
 * 获取工作流定义
 * @param {*} data
 * @returns
 */
export function getDeployList(data) {
    return request({
        url: url + '/flow/getDeployList',
        method: 'post',
        data,
    });
}

/**
 * 工作流实例
 * @param {*} data
 * @returns
 */
export function flowRun(data) {
    return request({
        url: url + '/flow/deploymentRun',
        method: 'post',
        data,
    });
}

5.request.js

import axios from 'axios';
const service = axios.create({});
service.defaults.timeout = 20000;
// 请求拦截器
service.interceptors.request.use(
    (config) => {
        return config;
    },
    (error) => {
        console.log(error);
        return Promise.reject(error);
    }
);
// 响应拦截器
service.interceptors.response.use(
    (response) => {
        return response.data;
    },
    (error) => {
        return Promise.reject(error);
    }
);

export default service;

四、后端代码(Flowable)

1.FlowController .java

@RestController
public class FlowController {
    @Autowired
    FlowService flowService;

    // 工作流部署(添加、编辑)
    @CrossOrigin
    @PostMapping("/flow/addFlow")
    public Result addFlow(@RequestBody Map<String,String> map){
        return flowService.AddFlow(map.get("id"), map.get("name"), map.get("xml"), map.get("key"));
    }

    // 工作流返回
    @CrossOrigin
    @PostMapping("/flow/infoFlow")
    public Result infoFlow(@RequestBody Map<String,String> map) {
        return flowService.InfoFlow(map.get("id"), map.get("name"));
    }

    // 工作流删除
    @CrossOrigin
    @PostMapping("/flow/deleteFlow")
    public Result deleteFlow(@RequestBody Map<String,String> map) {
        return flowService.DeleteFlow(map.get("id"));
    }

    // 工作流查询
    @CrossOrigin
    @PostMapping("/flow/getDeployList")
    public Result getDeployList() {
        return flowService.GetDeployList();
    }

    // 流程实例
    @CrossOrigin
    @PostMapping("/flow/deploymentRun")
    public Result deploymentRun(@RequestBody Map<String,String> map) {
        return flowService.DeploymentRun(map.get("userId"), map.get("key"));
    }

    // 流程查询
    @CrossOrigin
    @PostMapping("/flow/infoTask")
    public Result InfoTask(@RequestBody Map<String,String> map) {
        return flowService.InfoTask(map.get("userId"));
    }

    // 流程执行
    @CrossOrigin
    @PostMapping("/flow/makeTask")
    public Result MakeTask(@RequestBody Map<String,String> map) {
        return flowService.MakeTask(map.get("userId"));
    }

    // 流程历史
    @CrossOrigin
    @PostMapping("/flow/taskHistory")
    public Result TaskHistory() {
        return flowService.TaskHistory();
    }

    // 测试
    @CrossOrigin
    @PostMapping("/test")
    public Result test(@RequestBody AskForLeaveVO test) {
        return flowService.test(test);
    }


}

2.FlowService .java

@Service
public class FlowService {
    @Autowired
    ProcessEngine processEngine;
    @Autowired
    FlowTreeService flowTreeService;

    /**
     * 工作流部署(添加、编辑)
     * @param name 名称
     * @param xml xml
     * @return
     */
    @Transactional
    public Result AddFlow(String id, String name, String xml, String key){
        try {
            RepositoryService repositoryService = processEngine.getRepositoryService();
            // 创建新流程
            Deployment deployment = repositoryService.createDeployment()
                    .addString(name + ".bpmn", xml)
                    .deploy();

            // 将工作流信息保存到流程树表
            flowTreeService.AutoSave(id, deployment.getId(), key);
            System.out.println("id : " + id);
            System.out.println("添加id : " + deployment.getId());
            System.out.println("添加key : " + key);
            return Result.ok("添加成功", deployment.getId());

        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("添加失败");
        }
    }

    /**
     * 工作流返回(返回xml)
     * @param id 查询id
     * @param name 名称
     * @return
     */
    @Transactional
    public Result InfoFlow(String id, String name) {
        try {
            // 流程查询
            RepositoryService repositoryService = processEngine.getRepositoryService();
            InputStream resourceAsStream = repositoryService.getResourceAsStream(id, name + ".bpmn");
            // Java流转String
            String resultXml = new BufferedReader(new InputStreamReader(resourceAsStream,"utf-8"))
                    .lines().collect(Collectors.joining(System.lineSeparator()));

            return Result.ok("查询成功", resultXml);
        } catch (Exception e) {
            e.printStackTrace();
        }
        return Result.error("查询失败");
    }

    /**
     * 工作流删除
     * @param id
     * @return
     */
    @Transactional
    public  Result DeleteFlow(String id){
        try {
            RepositoryService repositoryService = processEngine.getRepositoryService();
            // 设置为TRUE 级联删除流程定义,及时流程有实例启动,也可以删除,设置为false 非级联删除操作。
            repositoryService.deleteDeployment(id);
            System.out.println("删除id : " + id);
            return Result.ok("删除成功", id);
        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("删除失败");
        }
    }

    /**
     * 工作流部署列表查询
     * @return
     */
    @Transactional
    public Result GetDeployList() {
        try {
            RepositoryService repositoryService = processEngine.getRepositoryService();
            List<ProcessDefinition> list = repositoryService.createProcessDefinitionQuery().list();
            System.out.println("list : " + list);
            return Result.ok("查询成功");
        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("查询失败");
        }
    }

    /**
     * 启动流程实例
     * @param userId 发起人
     * @param key 流程key
     * @return
     */
    @Transactional
    public Result DeploymentRun(String userId, String key){
        try {
//          Map<String, Object> variables = new HashMap<String, Object>();
//          variables.put("employee", userId);

            RuntimeService runtimeService = processEngine.getRuntimeService();
            ProcessInstance processInstance = runtimeService.startProcessInstanceByKey(key);
            //获取流程实例的相关信息
            System.out.println("流程定义的id = " + processInstance.getProcessDefinitionId());
            System.out.println("流程实例的id = " + processInstance.getId());
            return Result.ok("成功", "流程实例id = " + processInstance.getId());
        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("失败");
        }
    }

    /**
     * 查询流程任务
     * @param userId
     * @return
     */
    @Transactional
    public Result InfoTask(String userId){
        try {
            TaskService taskService = processEngine.getTaskService();
            // 查询多人任务
            List<Task> taskList = taskService.createTaskQuery().taskCandidateUser(userId).list();
            System.out.println("taskList" + taskList);
            //遍历任务列表
            for(Task task:taskList){
                System.out.println("流程定义id = " + task.getProcessDefinitionId());
                System.out.println("流程实例id = " + task.getProcessInstanceId());
                System.out.println("任务id = " + task.getId());
                System.out.println("任务名称 = " + task.getName());
            }
            return Result.ok("成功");
        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("失败");
        }
    }

    /**
     * 执行流程任务
     * @param userId
     * @return
     */
    @Transactional
    public Result MakeTask(String userId){
        try {
            TaskService taskService = processEngine.getTaskService();
            // 查询个人任务
            List<Task> list = taskService.createTaskQuery().taskCandidateUser(userId).list();
            System.out.println("taskList" + list);
            for (Task task : list) {
                taskService.complete(task.getId());
                System.out.println("task.getId()" + task.getId());
            }
            return Result.ok("成功");
        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("失败");
        }
    }

    /**
     * 查询历史流程
     * @param
     * @return
     */
    @Transactional
    public Result TaskHistory(){
        try {
            HistoryService historyService = processEngine.getHistoryService();
            List<HistoricActivityInstance> activities = historyService.createHistoricActivityInstanceQuery()
                    // .processInstanceId("12501") // 特定的实例
                    .finished() // 完成的
                            // .orderByHistoricActivityInstanceEndTime().asc() // 根据实例完成时间升序排列
                    .list();

            for (HistoricActivityInstance activity : activities) {
                System.out.println("id:" + activity.getActivityId() + "  任务名:" + activity.getActivityName() + "  类型:" + activity.getActivityType() + "  持续时间:" + activity.getDurationInMillis());
            }
            return Result.ok("成功");
        } catch (Exception e) {
            e.printStackTrace();
            return Result.error("失败");
        }
    }
}
转载请注明出处或者链接地址:https://www.qianduange.cn//article/1112.html
评论
发布的文章

Ajax用法总结

2024-02-14 09:02:07

JQuery之jsTree树形插件

2024-02-14 09:02:01

Why React Doesn‘t Need jQuery?

2024-02-14 09:02:00

jQuery模板字符串

2024-02-14 09:02:58

大家推荐的文章
会员中心 联系我 留言建议 回顶部
复制成功!
